Fremkit sietch

The widget registry for Fremkit, the widget dashboard for the Corsair Xeneon Edge on macOS. A sietch is where the Fremen keep the tribe's reserves, and where a newcomer is admitted once the tribe has seen what they bring — which is what this repository does with widgets. One folder per widget under widgets/; a workflow packs each folder into a zip, computes its hash and publishes an index.json on GitHub Pages that the Fremkit admin browses, installs from and checks for updates against.

• Registry: https://fdussert.github.io/fremkit-sietch/index.json
• Writing a widget: docs/writing-widgets.md in the main repository
• Publishing one here: CONTRIBUTING.md

A widget is plain HTML in a sandboxed iframe: it reaches the host only through the Fremkit bridge, and only for the channels, commands and network hosts its manifest declares. The Fremkit admin shows those permissions and asks for consent before installing, and again when a new version asks for more.

Widgets whose provider is in Fremkit

Most of what is published here needs nothing installed but Fremkit itself. A widget is HTML in a sandbox; the thing that holds an address, a token or a password is a provider or a connection type, and those stay in the core, where the secret can live in the keychain and never reach a page. So a widget that talks to a printer, a hub or an API is published here while the code that authenticates is already on the machine.

Widget	What it shows	Needs
bambu-job	The current job of a Bambu Lab printer	a bambu connection
homey-devices	Homey devices, with a touch to switch or dim one	a homey connection
homey-flows	Homey flows as buttons	the same homey connection
ado-pipelines	Azure DevOps pipeline runs, and a touch to start one	an azure-devops connection
github-actions	Workflow runs of the repositories being watched	a github connection
github-inbox	Reviews, issues and notifications waiting on GitHub	the same github connection
synology-storage	Volumes, disk health and temperature of a NAS	a synology connection
synology-system	CPU, memory, network and uptime of a NAS	the same synology connection
mutedeck	Microphone, camera and screen sharing of the meeting in progress	nothing — MuteDeck on this Mac
cleanshot	Big touch targets for CleanShot X captures	nothing — CleanShot X on this Mac

A connection is created once in the Fremkit admin, under Connections, and every widget of that type reads it. The install dialog names the connection a widget needs before you agree to it.

Layout

widgets/<id>/manifest.json   what the widget is, its version, the SDK it needs, its permissions
widgets/<id>/index.html      the widget
widgets/<id>/preview.webp    optional: its picture on the library card and the Sietch row
widgets/<id>/...             any asset it ships (images, fonts, scripts of its own)
themes/<id>/theme.json       a theme: colour tokens, no code, nothing to consent to
tools/                       the validator, the packer and the index builder (TypeScript, vitest)
tools/vendor/                byte-for-byte copies of Fremkit's manifest, zip and address rules
.github/workflows/           validate.yml on a pull request, publish.yml on main

The index.json and dist/ are generated: never edit them by hand, never commit them.

Building it locally

pnpm install
pnpm test          # the validator, the packer and the index builder
pnpm validate      # every rule, nothing written — what a pull request runs
pnpm build         # the same, plus dist/index.json, dist/widgets/*.zip, dist/previews/* and dist/index.html
pnpm check-vendor  # the vendored schema is still Fremkit's

pnpm validate and pnpm build read the index currently on Pages, so a version that does not go up is refused before merge, and older releases stay downloadable for a rollback.

What gets checked

A package is the widget's folder, zipped: manifest.json at the root, index.html, its assets. The CI refuses a folder that

• holds a dotfile, a symlink, a nested archive, an absolute or climbing path, or anything that is not a regular file;
• holds two names a Mac stores as one file: equal once lower-cased and Unicode-normalised (NFC), as APFS compares them — Fremkit's installer refuses such a package;
• is over 200 files, 5 MB zipped, 20 MB unpacked, or holds a file over 5 MB;
• has a manifest.json the Fremkit schema does not accept, or an id that is not the folder name;
• shows a text that is not a { "fr": …, "en": … } pair — the name, the description, every setting label, every list item label, every enum option label. Fremkit accepts a bare string for the sake of older manifests; a registry read by both languages does not. description is therefore required here, although the Fremkit schema treats it as optional: an absent one is not a pair, so leaving it out fails the check (the message says so — description is required, not a type error);
• asks for the config channel, which carries the whole dashboard and no Fremkit will grant;
• declares a private, loopback, link-local or .local-style host in permissions.network;
• loads a <script src=> from outside the package — the widget CSP would block it anyway;
• names a preview that is missing, over 200 KB, not the PNG or WebP its name says, or more than 15 % off twice the default size in pixels (see CONTRIBUTING); a widget with no preview is only a warning in the log, for now;
• reuses a published version, or goes backwards from it — and if the already-published index cannot be read at all, the build fails rather than guessing that nothing was published.

A widget's preview is published twice: inside its zip, where the installer expects it, and as previews/<id>-<version>.webp (or .png) on Pages, which the index entry names as preview. Fremkit shows only a preview on the registry's own host, so it is never linked from anywhere else; the path carries the version so a new picture is a new URL. Theme swatch colours in the index are held to Fremkit's colour shape, url( refused.

The zip is deterministic — sorted entries, a fixed timestamp, stored rather than compressed — so rebuilding an unchanged widget produces the same bytes, the same sha256, and no pointless update for anyone who already has it. The same folder packs to the same hash on any machine, in any timezone.

Testing the whole chain locally

Before anything is published there is nothing for a Fremkit to install from, so build the index against a local origin and serve it:

FREMKIT_REGISTRY_BASE=http://127.0.0.1:8080 pnpm build
npx serve dist -l 8080

Then point a development Fremkit at it. The registry URL is a constant there, and the override is honoured only under FREMKIT_DEV=1:

FREMKIT_DEV=1 FREMKIT_REGISTRY_URL=http://127.0.0.1:8080/index.json \
  FREMKIT_PORT=4301 FREMKIT_DATA_DIR=/tmp/fremkit-bench pnpm start

FREMKIT_REGISTRY_BASE matters because the index carries absolute URLs: without it the zips are advertised on the Pages origin, which a local dist/ is not. The build reads the published index to check that a version only ever goes up, and tolerates the 404 it gets on a first run.

Licence

MIT, for the registry and for every widget in it. By opening a pull request you publish your widget under that licence.

Fremkit is not affiliated with or endorsed by Corsair or any of the services a widget talks to; trademarks belong to their owners.
