Liquid Glass

Figma's Liquid Glass effect, rebuilt as a real-time WebGL2 renderer.

Design the glass in the browser, then export a config you can paste anywhere.

Live site → · Open the editor → · Guide →

---

What it does

Real refraction, not a blur filter. A signed distance field is built from any shape, turned into a height field, and used to bend the background per pixel on the GPU — with chromatic dispersion, frost, and specular light.

• Any shape — rectangles, ellipses, pills, polygons, stars, or paste your own SVG path
• Figma-accurate controls — Refraction, Depth, Dispersion, Frost, Splay, Light
• Two controls Figma doesn't have — see below
• Copy-paste configs — export JSON, import it back, share it
• Presets — seven starting points, one click each

Controls

Control	What it does
Refraction	How hard the background bends
Depth	How thick the glass reads
Dispersion	Chromatic splitting at the curved edge
Frost	Background blur through the glass
Splay	How widely projected light spreads (needs Light intensity > 0)
Reach	How far the bevel reaches inward. High values turn the whole shape into a lens instead of a flat pane with a bevelled border.
Soften	Rounds off the creases that fan in from the corners once Reach is wide, so the lens becomes a smooth dome instead of a faceted one.

Reach and Soften go beyond Figma. Figma's bevel is pinned near the border, which caps how much the glass can behave like a real lens; Reach lifts that cap. Soften then blurs the distance field before the rim profile is applied — tapered so the border keeps its exact distance and only the interior smooths, which is what removes the corner creases without draining the refraction.

A config to start from

{
  "glass":  { "lightAngle": -45, "lightIntensity": 20, "refraction": 100, "depth": 100, "dispersion": 0, "frost": 22, "splay": 4 },
  "layer":  { "x": 320, "y": 119.75, "w": 313, "h": 296 },
  "solver": { "reach": 100, "soften": 24, "smooth": 4, "gain": 160, "chroma": 1.0, "spread": 0.26, "fall": 1.6, "dark": 0, "tint": 0.02 }
}

Paste it into the editor's config box and hit Apply.

Run it locally

npm install
npm run dev     # http://localhost:5173
npm run build

How it's built

No framework, no renderer library — vanilla JS and one WebGL2 fragment shader.

• Field — exact Euclidean distance transform (Felzenszwalb & Huttenlocher), a rim profile, and a Sobel pass, packed into an RGBA32F texture as (gx, gy, height, coverage). Storing the gradient instead of differencing height in the shader is worth about 100× in signal-to-noise and saves eight texture fetches per pixel.
• Threading — the field build costs ~42 ms at drag resolution and ~830 ms at full, so it runs in a Web Worker. The main thread only uploads, which keeps the sliders at full framerate.
• Precision — falls back to RGBA16F where OES_texture_float_linear is unavailable.
• Scroll — Lenis.

src/
  renderer.js      WebGL2 pipeline + shaders
  sdf.js           distance transform, rim profile, Sobel
  field-worker.js  the build, off the main thread
  state.js         params, solver constants, shape model
  ui.js            panel bindings
  interact.js      canvas drag/resize
  landing.js       landing page
public/
  guide.html       full control reference

Credits

Built by Miftahul Islam Efaz. Effect inspired by Figma's Liquid Glass.
