Train model on Titanic dataset

In this tutorial, we’ll create a pipeline that does the following:

1. Load data from an online endpoint
2. Select columns and fill in missing values
3. Train a model to predict which passengers will survive

If you prefer to skip the tutorial and view the finished code, follow this guide.

Table of contents

1. Setup
2. Create new pipeline
3. Play around with scratchpad
4. Load data
5. Transform data
6. Train model
7. Run pipeline

1. Setup

1a. Initialize project

In your terminal, run this command:

Docker

./scripts/init.sh demo_project

pip

mage init demo_project

2a. Start the tool

Docker

./scripts/start.sh demo_project

pip

mage start demo_project

Open http://localhost:6789 in your browser.

3a. Add Python packages to project

In the left sidebar (aka file browser), click on the requirements.txt file under the demo_project/ folder.

Then add the following dependencies to that file:

matplotlib
requests
scikit-learn

4a. Install dependencies

The simplest way is to run pip install from the tool.

Add a scratchpad block by pressing the + Scratchpad button. Then run the following command:

%pip install -r demo_project/requirements.txt

Alternatively, here are other ways of installing dependencies (depending on if you are using Docker or not):

Docker

Get the name of the container that is running the tool:

docker ps

Sample output:

CONTAINER ID   IMAGE       COMMAND                  CREATED         STATUS         PORTS     NAMES
214e1155f5c3   mage/data   "python mage_ai/comm…"   5 seconds ago   Up 2 seconds             mage-ai_server_run_6f8d367ac405

The container name in the above sample output is mage-ai_server_run_6f8d367ac405.

Then run this command to install Python packages in the demo_project/requirements.txt file:

docker exec [container_name] pip3 install -r demo_project/requirements.txt

pip

If you aren’t using Docker, just run the following command in your terminal:

pip3 install -r demo_project/requirements.txt

2. Create new pipeline

In the top left corner, click File > New pipeline. Then, click the name of the pipeline next to the green dot to rename it to titanic survivors.

3. Play around with scratchpad

There are 4 buttons, click on the + Scratchpad button to add a block.

Paste the following sample code in the block:

import matplotlib.pyplot as plt
import numpy as np


t = np.arange(0.0, 2.0, 0.01)
s = 1 + np.sin(2*np.pi*t)
plt.plot(t, s)

plt.xlabel('time (s)')
plt.ylabel('voltage (mV)')
plt.title('About as simple as it gets, folks')
plt.grid(True)
plt.show()

Then click the Play button on the right side of the block to run the code. Alternatively, you can use the following keyboard shortcuts to execute code in the block:

• Command + Enter
• Control + Enter
• Shift + Enter (run code and add a new block)

Now that we’re done with the scratchpad, we can leave it there or delete it. To delete a block, click the trash can icon on the right side or use the keyboard shortcut by typing the letter D and then D again.

4. Load data

1. Add a new data loader block by clicking the + Data loader button.
2. Rename the block to load dataset.
3. Paste the following code and run the block:

from pandas import DataFrame
import io
import pandas as pd
import requests

if 'data_loader' not in globals():
    from mage_ai.data_preparation.decorators import data_loader


@data_loader
def load_data() -> DataFrame:
    response = requests.get(
      'https://raw.githubusercontent.com/datasciencedojo/datasets/master/titanic.csv',
    )

    return pd.read_csv(io.StringIO(response.text), sep=',')

After you run the block, you can immediately see a sample of the data in the block’s output.

On the far right side of the screen (aka the Sidekick), there are 5 tabs you can explore:

1. Tree: shows the dependencies of each block
2. Data: detailed information of the underlying data
3. Reports: data quality, feature profiles, etc.
4. Graphs: charts
5. Variables: how to access variables produced in other blocks

Every data loader and transformer block will have its own state of information displayed on the right side.

5. Transform data

We’re going to select numerical columns from the original dataset, then fill in missing values for those columns (aka impute).

1. Add a new transformer block by clicking + Transformer button.
2. Click the link in the top right corner of the block labeled Click to set parent blocks.
3. On the right side under the Tree tab, select the block named load_dataset, then click the Save dependencies button.
4. Rename the block to extract and impute numbers.
5. Paste the following code in the block:

from pandas import DataFrame
import math


if 'transformer' not in globals():
    from mage_ai.data_preparation.decorators import transformer


def select_number_columns(df: DataFrame) -> DataFrame:
    return df[['Age', 'Fare', 'Parch', 'Pclass', 'SibSp', 'Survived']]


def fill_missing_values_with_median(df: DataFrame) -> DataFrame:
    for col in df.columns:
        values = sorted(df[col].dropna().tolist())
        median_age = values[math.floor(len(values) / 2)]
        df[[col]] = df[[col]].fillna(median_age)
    return df


@transformer
def transform_df(df: DataFrame, *args) -> DataFrame:
    return fill_missing_values_with_median(select_number_columns(df))

6. Train model

In this part, we’re going to accomplish the following:

1. Split the dataset into a training set and a test set.
2. Train logistic regression model.
3. Calculate the model’s accuracy score.
4. Save the training set, test set, and model artifact to disk.

Here are the steps to take:

1. Add a new data exporter block by clicking + Data exporter button.
2. Click the link in the top right corner of the block labeled Click to set parent blocks.
3. On the right side under the Tree tab, select the block named extract_and_impute_numbers, then click the Save dependencies button.
4. Rename the block to train model.
5. Paste the following code in the block:

from pandas import DataFrame
from sklearn.linear_model import LogisticRegression
from sklearn.metrics import accuracy_score
from sklearn.model_selection import train_test_split
import os
import pickle

if 'data_exporter' not in globals():
    from mage_ai.data_preparation.decorators import data_exporter


LABEL_COLUMN = 'Survived'


def build_training_and_test_set(df: DataFrame) -> None:
    X = df.drop(columns=[LABEL_COLUMN])
    y = df[LABEL_COLUMN]

    return train_test_split(X, y)


def train_model(X, y) -> None:
    model = LogisticRegression()
    model.fit(X, y)

    return model


def score_model(model, X, y) -> None:
    y_pred = model.predict(X)

    return accuracy_score(y, y_pred)


@data_exporter
def export_data(df: DataFrame) -> None:
    X_train, X_test, y_train, y_test = build_training_and_test_set(df)
    model = train_model(X_train, y_train)

    score = score_model(model, X_test, y_test)
    print(f'Accuracy: {score}')

    cwd = os.getcwd()
    filename = f'{cwd}/finalized_model.lib'
    print(f'Saving model to {filename}')
    pickle.dump(model, open(filename, 'wb'))

    print(f'Saving training and test set')
    X_train.to_csv(f'{cwd}/X_train')
    X_test.to_csv(f'{cwd}/X_test')
    y_train.to_csv(f'{cwd}/y_train')
    y_test.to_csv(f'{cwd}/y_test')

7. Run pipeline

We can now run the entire pipeline end-to-end. In your terminal, execute the following command:

mage run demo_project titanic_survivors

Your output should look something like this:

Executing data_loader block: load_dataset...DONE
Executing transformer block: extract_and_impute_numbers...DONE
Executing data_exporter block: train_model...Accuracy: 0.757847533632287
Saving model to /home/src/finalized_model.lib
Saving training and test set
DONE

---

Congratulations!

You’ve successfully built an ML pipeline that consists of modular code blocks and is reproducible in any environment.
